OVERVIEW
Our cutting-edge single phase capacitance tester is designed to simplify the measurement of shunt capacitors in a single group without the need for wire removal. Employing advanced measuring principles and four-terminal measurement technology, ensures precise and reliable testing with excellent repeatability.
Capacitance Measurement Capabilities
- The instrument allows for quick and accurate measurement of the capacitance of a single capacitor in a group, eliminating the time-consuming process of disconnecting wires. Its sophisticated design and technology ensure that measurements are consistent and in line with industry standards.
Inductance Measurement
- In addition to capacitance measurement, the single phase capacitance tester is also capable of measuring the inductance of various reactor types. This versatility makes it an invaluable tool for a wide range of applications in the field of electrical engineering.
Operational Advantages
- It offers a range of operational advantages, including convenient wiring and a user-friendly interface. Its straightforward operation reduces the workload of maintenance personnel, significantly enhancing field test efficiency. By streamlining the measurement process, it provides an added layer of security for the normal operation of the power grid.
CHARACTERISTIC
Real-Time Measurement and Analysis
- During measurements, the device displays the measured capacitance or inductance values alongside vital data such as voltage, current, power, frequency, impedance, and phase angle, enabling a comprehensive analysis of the sample’s quality.
Advanced User Interface
- The device features an 8.0-inch 800 × 600 graphics dot matrix K600 + 65K color dgus screen with touch control operation, ensuring clear visibility and an intuitive menu for easy operation, day or night.
Data Storage and Retrieval
- With built-in large capacity nonvolatile memory, the device can store up to 200 groups of measurement data. It also includes a U disk interface for additional data storage, limited only by the capacity of the U disk.
Timekeeping and Documentation
- The device is equipped with a high-precision real-time clock function for date and time calibration. It further includes a high-speed micro thermal printer for printing measurement and historical data, providing a physical record of all analyses.
Safety and Protection
- The device features an instrument test power over-current protection function, safeguarding against damage in the event of a power output short circuit.
